• Check that the pressure gauge works — on suction the needle must reach the green zone (0.25 bar).
• Check the power cord and plug — a damaged cord excludes the unit from work.
• Check the safety devices and the load safety chain.
• Make sure the load surface is dry, clean and free of ice.

1. Switch off the vacuum generator and unplug the power cord.
2. Carefully lay the vacuum lifter on its side.
3. Clean the dust filter with a soft brush.

Clean the filter at least once a week — more often in dusty conditions. A heavily soiled or damaged filter can damage the lifter — replace a worn filter with a new one.

• Inspect and clean the suction plate seals every month; replace worn ones with genuine UP GECO parts.
• Clean suction plates at least once a week with a soft brush and a pH-neutral cleaning agent; let them dry completely.
• Do not use wire brushes, abrasive paper or aggressive chemicals.
• A damaged sealing edge of the suction plate = replace the suction plate.

1. Check that the suction plate rests on the load with its entire surface (over the centre of gravity).
2. Check that the load is not porous, cracked or wet — such loads must not be lifted with a vacuum lifter.
3. Clean the dust filter.
4. Check the seal of the suction plate and the mounting plate.
5. Test on a smooth, dense load without lifting — the gauge must reach 0.25 bar.

• Store the lifter unplugged, on a clean and level surface (to protect the seal), sheltered from the weather.
• Do not rest the lifter on its suction plates.
• Store suction plates at 0°C to +25°C — dry, dark, away from UV light, ozone and draughts.

Repairs of the electrical system, the vacuum generator and load-bearing parts, and any modification of the unit, are carried out exclusively by the authorised UP GECO service. If the checks above do not restore normal operation — stop using the unit and request a repair.

• Check the safety devices and the operation of the pressure gauge and indicator lamps.
• Check the power cord (thorough inspection weekly).
• Connect the unit only to an earthed socket, on a circuit protected by a residual-current device.
• During work breaks longer than 2 minutes, switch the vacuum generator off.

1. Switch off the vacuum generator and unplug the power cord.
2. Carefully lay the vacuum lifter on its side.
3. Clean the filter screen (dust filter) with a soft brush.

Clean at least once a week; if the motor draws more power than usual, cleaning the filter screen is the first step.

• Inspect and clean the suction plate seals every month; replace worn ones with genuine UP GECO parts.
• When mounting a suction plate there must be a clean seal between the plate and the mounting plate; tighten the plate with ISO 7380 M8x20 screws to 23 Nm.
• Clean suction plates weekly with a soft brush and a pH-neutral agent — no wire brushes or aggressive chemicals.

1. Position the lifter so the suction plate rests with its entire surface — air leaking in is the most common cause.
2. Clean the filter screen.
3. Check the seals of the suction and mounting plates and the sealing edge.
4. Check the pressure gauge — replace it if damaged.
5. A porous or cracked load, or working above 1600 m above sea level = the unit will not reach the required vacuum (this is not a fault).

• Store unplugged, on a clean and level surface, sheltered from the weather; do not rest it on the suction plates.
• Suction plates: 0°C to +25°C, dry, dark, no UV or ozone — these factors greatly shorten the life of rubber parts.

Installation and service only by qualified mechanics and electricians. Repairs of electrical connections, the vacuum generator, load-bearing parts and any modifications — authorised UP GECO service only. Request a repair →

• Check the pressure gauge and the optical vacuum indicator (its red part retracts when the unit is ready to work).
• Check hydraulic hoses and connections for damage and leaks (thorough inspection weekly).
• Check the safety devices and the load safety chain.
• Lift the load only once the gauge shows 0.4 bar and the optical indicator confirms readiness.

1. Switch off the vacuum generator and disconnect the lifter from the hydraulic supply.
2. Carefully lay the lifter on its side so it rests on the handles.
3. Unscrew the suction plate and the adapter.
4. Unscrew the filter mounting and clean the filter with compressed air.

After removing the adapter, check the condition of the seals in the adapter — clean or replace them if needed. Clean the filter at least once a week.

• Inspect and clean the suction plate seals every month; replace worn ones with genuine UP GECO parts.
• When mounting a suction plate the seal between the plate and the adapter must be clean; tighten the plate with ISO 7380 M8x20 screws to 23 Nm.
• Clean suction plates weekly with a soft brush and a pH-neutral agent (ultrasonic cleaning is also possible); dry at room temperature.

1. Position the lifter so the suction plate rests on the load with its entire surface.
2. Clean the air filter; replace it if damaged.
3. Check the sealing edge of the suction plate and the seals — replace worn parts.
4. Check the pressure gauge — replace it if damaged; report a faulty optical indicator to the service.
5. Overheated generator: detach the suction plate from the load and ventilate the unit.
6. Tightness test: grip a smooth, dense load without lifting — minimum 0.4 bar required.

• Store disconnected from the supply, on a clean and level surface, sheltered from the weather; do not rest it on the suction plates.
• Suction plates: 0°C to +25°C, dry, dark, no UV, ozone or draughts.

Work on the hydraulic system may be carried out only by qualified mechanics. Repairs of the hydraulic system, the vacuum generator, the optical indicator, load-bearing parts and any modifications — authorised UP GECO service only. Request a repair →
